Filter Kit C – Rainwater Harvesting
- Description
Filter Kit C is designed for roofs up to 800 square meters and includes a two-stage rainwater filter unit, siphon overflow, and calmed inlet.
Upon entering the filter, water first passes through the initial cascade to remove larger debris particles. The pre-filtered water then continues through the secondary sieve filter with a mesh size of 0.65 mm, effectively capturing any remaining debris.
The purified water flows into the tank through a calmed inlet, ensuring minimal turbulence and preserving sediment undisturbed at the tank bottom. This method of rainwater entry also oxygenates the water, preventing anaerobic decomposition.
Lastly, the overflow siphon, featuring a skimming inlet, removes additional debris, oils, and floating contaminants from the water's surface.
Features:
- Designed for roof sizes up to a maximum of 800 sq metres (per kit)
- For installation in a pilot shaft or against the wall in frost-protected areas
- Available pre-installed in pilot shaft
- Two step cleaning system independent of flow rate ensuring high filtering efficiency
- Filter cartridge location assists continuous removal of dirt
- Suitable for 110mm (4”) and 160mm (6”) down pipes
- Filter unit weight 16 kg
- Siphon overflow with skimming inlet
- Siphon overflow pipe to fit a 130 mm hole in storage tank wall
- Calmed inlet to prevent incoming water disturbing any sediment in tank
- Calmed inlet also ensures fresh water is supplied to lower area of the tank resulting in complete and regular replenishment of stored water
